| XLTR500 Air Cooled MIG GUN | ||||
| Technical Data： | Rating:500A CO2/400A Mixed Gases | |||
| Duty Cycle: 60% | ||||
| Wire Size: .040''-3/32''(1.0--2.4mm) | ||||
| Type | 10ft(3.0m) | 12ft(3.5m) | 15ft(4.5m) | |
| XLTR500 MIG GUN Miller Connector | XL5010M | XL5012M | XL5015M | |
| XLTR500 MIG GUN Tweco Connector | XL5010T | XL5012T | XL5015T | |
| XLTR500 MIG GUN Lincoln Connector | XL5010L | XL5012L | XL5015L | |
| XLTR500 MIG GUN Euro Connector | XL5010E | XL5012E | XL5015E | |
| No. | Description | Order | ||
| A | Nozzle 1/2" 12.7mm 1/4" Recess Copper | XL401-5-50 | ||
| Nozzle 3/4" 19mm 1/4" Recess Copper | XL401-5-75 | |||
| Nozzle 5/8” 15.9mm 1/4" Recess Copper | XL401-5-62 | |||
| Nozzle 1/2" 12.7mm 1/8” Recess Copper | XL401-6-50 | |||
| Nozzle 5/8" 15.9mm 1/8" Recess Copper | XL401-6-62 | |||
| Nozzle 3/4" 19mm 1/8" Recess Copper | XL401-6-75 | |||
| Nozzle 5/8” 15.9mm 1/4" Recess Brass | XL401-7-62 | |||
| Nozzle 3/4" 19mm 1/8” Recess Brass | XL401-7-75 | |||
| Nozzle 5/8" 15.9mm 1/8” Recess Brass | XL401-71-62 | |||
| Nozzle 5/8” 15.9mm Flush Bottleneck Copper | XL401-48-62 | |||
| Nozzle 5/8” 15.9mm 1/8” Stick Out Brass | XL401-87-62 | |||
| Nozzle 5/8” 15.9mm 1/8” Stick Out Copper | XL401-81-62 | |||
| B | Contact Tip .030'' 0.8mm Heavy Duty | XL403-20-30 | ||
| Contact Tip .035'' 0.9mm Heavy Duty | XL403-20-35 | |||
| Contact Tip .040'' 1.0mm Heavy Duty | XL403-20-40 | |||
| Contact Tip .045'' 1.2mm Heavy Duty | XL403-20-45 | |||
| Contact Tip .052'' 1.4mm Heavy Duty | XL403-20-52 | |||
| Contact Tip 1/16'' 1.6mm Heavy Duty | XL403-20-116 | |||
| Contact Tip 5/64'' 2.0mm Heavy Duty | XL403-20-564 | |||
| Contact Tip 3/32'' 2.4mm Heavy Duty | XL403-20-332 | |||
| Contact Tip .030'' 0.8mm Heavy Duty Tapered | XL403-21-30 | |||
| Contact Tip .035'' 0.9mm Heavy Duty Tapered | XL403-21-35 | |||
| Contact Tip .040'' 1.0mm Heavy Duty Tapered | XL403-21-40 | |||
| Contact Tip .045'' 1.2mm Heavy Duty Tapered | XL403-21-45 | |||
| Contact Tip .052'' 1.4mm Heavy Duty Tapered | XL403-21-52 | |||
| Contact Tip 1/16'' 1.6mm Heavy Duty Tapered | XL403-21-116 | |||
| Contact Tip 5/64'' 2.0mm Heavy Duty Tapered | XL403-21-564 | |||
| Contact Tip 3/32'' 2.4mm Heavy Duty Tapered | XL403-21-332 | |||
| C | Gas Diffuser | XL404-20 | ||
| Gas Diffuser Dual Taper | XL404-26 | |||
| Gas Diffuser | XL404-30 | |||
| Gas Diffuser Dual Taper | XL404-32 | |||
| D | Neck Insulator | XL402-11 | ||
| E | Liner for 1/16"-5/64" (1.6-2.0mm) 10FT(3.0m) | XL415-564-10 | ||
| Liner for 1/16"-5/64" (1.6-2.0mm) 15FT(4.6m) | XL415-564-15 | |||
| Liner for .078"-3/32" (2.0-2.4mm) 15FT(4.6m) | XL415-332-15 | |||
| Liner for .078"-3/32" (2.0-2.4mm) 25FT(7.6m) | XL415-332-25 | |||
| No. | Description | Order | ||
| 1 | Swan Neck 45° | XL505-45 | ||
| Swan Neck 60° | XL505-60 | |||
| 2 | Torch Body Assembly | XL407 | ||
| 3 | Handle | XL410 | ||
| 4 | Switch | XL411-1 | ||
| 5 | Switch The Trigger | XL411-2X | ||
| 6 | End Fitting | XL408 | ||
| 7 | Cone Nut | XL509 | ||
| 8 | Cable Ball Joint & Support Spring Big | XL400.1010B | ||
| 9 | Cable Assembly | |||
| 10 | Euro Direct Plug Kit | XL1199E | ||
| 10-1 | Rear Handle | XL501.2248 | ||
| 10-2 | Adaptor nut | XL4861 | ||
| 10-3 | Euro Central Connector | XL5060 | ||
| 11 | Rear Handle American Brand | XL2520047 | ||
| 12 | Control Wire (Tweco/Miller) | XLMAK-354 | ||
| 12-1 | Control Wire (Lincoln) | XLLAK-354 | ||
| 13 | Tweco Central Connector | XL2200103 | ||
| 14 | Miller Central Connector | XL2200101 | ||
| 15 | Lincoln Central Connector | XL2200099 | ||
| 15-1 | Gas Tube | XLLKGAS | ||
