WP/SR-17 TORCH-EURO (Gas and Power Separate)

WP/SR-17 TORCH-ERUO Air-Cooled Tig Welding Torch Rating: 150A DC/115A AC @ 60% Duty Cycle .020"-1/8"/0.5-3.2mm Electrodes No. Part Number Description WP-17-2-4M WP-17 Torch (Gas and Power Separate) 4m WP-17-2-8M WP-17 Torch (Gas and Power Separate) 8m

Products Details

WP/SR-17 TORCH-ERUO
Air-Cooled Tig Welding Torch
Rating: 150A DC/115A AC @ 60% Duty Cycle
.020"-1/8"/0.5-3.2mm Electrodes
No. Part Number Description
WP-17-1-4M WP-17 Torch (Gas and Power Whole) 4m
WP-17-1-8M WP-17 Torch (Gas and Power Whole) 8m
WP-17-2-4M WP-17 Torch (Gas and Power Separate) 4m
WP-17-2-8M WP-17 Torch (Gas and Power Separate) 8m
A Stubby Series
B Standard Series
C Stubby Gas Lens Series
D Gas Lens Series
E Large Gas Lens Series
No. Part Number Description
1 WP-17 Torch body
2 98W18 Back Cap 'O' Ring
3 57Y04 Short Back Cap
4 57Y05 Medium back cap
5 57Y02 Long back cap
6 H-200SDC Small Tig Handle Double Color
7 XL1MS Momentary Kit
8 57Y01RE Rubber Power Cable 4m
57Y03RE Rubber Power Cable 8m
9 57Y01-2E Power Cable Optional 2PC 4m
57Y03-2E Power Cable Optional 2PC 8m
10 XL5SL Switch Lead
11 XLKLS Knuckle Joint & Lock Nut Small
12 XLNV20 Neoprene Cover
13 XLPCM12 Power Cable Connection M12*1
14 XLE1025 Power Cable Connection Euro10-25
15 XL501.0114 Gas Connection Plug Nipple ND 5mm
16 XLPGX16 Switch Wire Plug GX-16
17 XLIBR Insulating Blanket Rubber
18 XLPA1225 Power Cable Adaptor M12/10-25
17EURO
